First, the non-adhesive plastic material tensile testing machine Uses: Widely used in the mechanical analysis test building materials, aerospace, machinery manufacturing, wire and cable, rubber, plastics, textiles, non-sticky plastic material, appliance and other industries, scientific research institutions , universities, industrial and mining enterprises, technical supervision, inspection and arbitration department ideal test equipment.

     Second, the non-adhesive plastic material tensile testing machine uses: The main technical indicators:

1, the maximum test force: 2000N;

2, Range: 0N-2000N;

3, the test force accuracy: better than ± 1%

4, the displacement resolution: 0.01mm;

5, the displacement measurement accuracy: better than ± 1%;

6, tensile stroke: 800mm (according to user-specific requirements)

7, the compression stroke: 800mm (according to user-specific requirements)

8 Test itinerary: 800mm (according to user-specific requirements)

9, the displacement speed control range: 0.2mm / min ~ 500mm / min (common configuration)

10, the displacement speed control accuracy: better than ± 1%

11, the test machine level: better than Class 1

12, the test machine size: 530 * 266 * 1810 mm

13, Appearance: meet GB / T2611 requirements

14, Complete Set: meet the standard requirements

15, the protection function: testing machine overload protection function

16, power supply: 220V, 50Hz

17, Weight: 150 kg
